MAHR MarSurf GD 280 Roughness measuring station(1)

MAHR MarSurf GD 280 Roughness measuring station

MarSurf GD: The new reference measuring station for roughness and waviness measurements

The new Mahr measuring stations from the MarSurf GD series are setting new standards.In addition to surface roughness evaluations, profile, and waviness evaluations can also be performed. The new MarSurf GD series is enabling production companies to achieve a new dimension to reliably ensure and improve the production quality of workpieces in the measuring room or close to the production area.

The new measuring station concept combines speed, security, and flexibility. The aim is to increase the cost-effectiveness of the system for your company.

The measuring stations are operated with the user-friendly MarWin software (MarWin EasyRoughness or MarWin ProfessionalRoughness).

Ask Question
Categories: , Product ID: 3861

Description

MarSurf GD 280 Roughness measuring station

Innovative technologies:

Fast axes

  • Positioning speeds up to 200 mm/s in X
  • 40 x faster than its predecessor MarSurf GD 120
  • The Z-axis is fully CNC-capable by default
  • The Z-axis is approx. twice as fast as previous Mahr Z-axes
  • Up to 5 times faster than standard Z-axes on the market
  • Contacting and zeroing via the Z-axis

New flexible probe system mount with BFW probe system

  • Simple probe arm change and probe arm protection by means of magnetic probe arm holder
  • Probe arm holder allows the change from standard to transverse measurement without tools or adapters
  • Extensions for the touch probe are possible

Innovative workpiece clamping system

  • Mounting plate 390 x 430 mm with bore dimension 50 mm
  • Integrated 60 mm TY adjustment
  • The combination of mounting plate and integrated TY adjustment makes an additional XY table superfluous
  • Low workpiece setup supports a favorable short measurement loop, which has a positive effect on the measurement results

Technical Data
MarSurf GD 280
MarSurf GD 140
Resolution
Measuring range 1: 7.6 nm
Measuring range 2: 0.76 nm
Measuring range 1: 7.6 nm
Measuring range 2: 0.76 nm
Start of traversing length (in X)
0 mm
0 mm
Probe arm length
45 mm (x 1)
67.5 mm (x 1,5)
90 mm (x 2)
112.5 mm (x 2,5)
135 mm (x 3)
45 mm (x 1)
67.5 mm (x 1,5)
90 mm (x 2)
112.5 mm (x 2,5)
135 mm (x 3)
End of traversing length (in X)
280 mm
140 mm
Positioning speed
0.02 – 200 mm/s (in X)
0.02 – 200 mm/s (in X)
Guide deviation
0.07 µm / 20 mm
0.2 µm /  60 mm
0.4 µm / 140 mm
0.07 µm / 20 mm
0.2 µm /  60 mm
0.4 µm / 140 mm
Measuring speed
Up to 10 mm/s
Up to 10 mm/s
Measuring range mm
500 µm (±250 µm) for probe arm length 45 mm
1500 µm (±750 µm) for probe arm length 135 mm
500 µm (±250 µm) for probe arm length 45 mm
1500 µm (±750 µm) for probe arm length 135 mm



Applications

Mechanical Engineering

  • Bearings, threads, threaded bars, ball screws, shafts, racks

Production metrology

  • Contour measurement in a semi-automatic process

Automotive industry

  • Steering, brake system, gearbox, crankshaft, camshaft, cylinder head

Medical technology

  • Contour of hip and knee endoprosthesis, contour of medical screws, contour of dental implants

Accessories

Optional:

  • Manual control panel with joystick and display
  • Motor-driven TY axis
  • Parallel vice
  • Prism block
  • Equipment table
  • Vibration damping system

General software options:

  • Option – RoughnessPlus
  • Option – MeasurementPlus
  • Option – Dominant Waviness (WDc) for MarWin
  • Option – ISO 13565-3 surface parameters
  • Option – QS-STAT / QS-STAT Plus
  • Option – Profile processing
  • Option – User-defined parameters
  • Option – Topography

Versions

MarSurf GD 140 BG 12

  • 140 mm X-axis
  • 350 mm Z-axis
  • With angle adjustment of the X-axis
  • Roughness tracing system BFW

Further measuring station components:

  • Computer and monitor
  • Software MarWin EasyRoughness or MarWin ProfessionalRoughness

MarSurf GD 140 BG 22

  • 140 mm X-axis
  • 600 mm Z-axis
  • With angle adjustment of the X-axis
  • Roughness tracing system BFW

Further measuring station components:

  • Computer and monitor
  • Software MarWin EasyRoughness or MarWin ProfessionalRoughness

MarSurf GD 280 BG 12

  • 280 mm X-axis
  • 350 mm Z-axis
  • With angle adjustment of the X-axis
  • Roughness tracing system BFW

Further measuring station components:

  • Computer and monitor
  • Software MarWin EasyRoughness or MarWin ProfessionalRoughness

MarSurf GD 280 BG 22

  • 280 mm X-axis
  • 600 mm Z-axis
  • With angle adjustment of the X-axis
  • Roughness tracing system BFW

Further measuring station components:

  • Computer and monitor
  • Software MarWin EasyRoughness or MarWin ProfessionalRoughness
